H6 Hybrid

H6 Hybrid

The Carrier H6 Hybrid is our flagship heavy-lift gas-electric hybrid drone powered by either our H2400 EFI generator. The Carrier H6 Hybrid’s airframe is fully convertible to hydrogen-electric (Carrier H6 Hydrone), or fully electric (Carrier H6 HE+). The H6 is the only aircraft in the world that has three power formats, all of which take just minutes in conversion times.

The Carrier H6 Hybrid HE+ is equipped with the H2400 generator providing 2400W of continuous power. The system can fly for up to 2.5 hours with a 4kg payload.. The max payload is 5kg allowing up to 1.5hrs of flight.

The system is popular for many applications including but not limited to: LiDAR surveying, photogrammetry, utility inspections, large corridor mapping, surveillance, and many more.

Features

Plug-and-Play EFI (Electronic Fuel Injection) 2.4kW continuous power generator
Dual Generator and Battery Power
Extra power provided against harsh wind or aggressive flight maneuvers
Fully convertible to all electric (LiPo batteries) and Hydrogen-electric power formats in minutes
Folds down to 45% of its flight-ready size for easy transportation
Modular payload bay with varying power outputs and connections
Rapid Field Deployment in several minutes

Intuitive GCS Telemetry

Easy Mission Planning
System status and warning flags with 10 telemetry channels for the generator system.
Generator mode states: Stop, Idle, Run; all controllable via GCS screen and/or 3 position switch on GCS.
Real-time fuel level % display from high accuracy EFI fuel flow sensor.
Compatible with Windows, Android, and iOS devices.
